Commercial pressurized water tank

Commercial Pressurized Water Tank

From 0.5 tons to 30 tons

Note: The above inner tank is round bottom and round top cover, the outer tank is flat bottom and flat top cover, the bracket is carbon steel, 0.5~10 tons does not include inspection port, the material is from Baosteel (inner stainless steel 304, outer stainless steel 201)

Stainless steel 316L for inner tank for option.

All connection sizes based on customer's requirement.1. Material thickness: outer tank stainless steel 201-0.6 mm,

Inner tank ±30C or so:

0.5 tons~2.5 tons 3 mm

3 tons ~ 6 tons 4mm

6.5 tons~9 tons 5mm

12.5 tons~20 tons 6mm

25 tons~30 tons 8mm

Atmospheric pressure 6 kg

2.Packaging: with safety valve and pressure gauge.
